Water heater installation height

Water heaters are a commonly used household appliance in daily life. They are mainly a tool for providing hot water. They heat water and use some natural gas or energy to heat water to provide hot water for bathing. The installation height of the water heater in daily life is also something that needs attention. The most suitable height is mainly when the light outlet is at the same level as the human eye. The water heater must be installed in a well-ventilated room.

After the connection is completed, a tightness test must be carried out. You can first pass water through the water heater, and then if the water flow is normal, check whether the water heater is leaking. When installing the water heater, you must pay attention to the installation height. The water pipe of the gas pipe of the water heater should not be too long. At the same time, it must be well supported and fixed. You should pay attention to check for water leaks frequently.

The installation height of the water heater should be such that the fire viewing hole is level with the human eye. The water heater should not be installed above furniture. The smoke exhaust outlet of the water heater should be more than 600 mm away from the ceiling, and the distance from other open surfaces to combustibles should be more than 300 mm. When installing the water heater, the following points should be paid special attention to:

1. The water heater must be installed in a well-ventilated room and never in a bathroom or bedroom. A flue must be installed on a flue-type water heater.

2. The water inlet, water outlet and air inlet joints should be distinguished. Do not connect the air to the water line, and do not connect the water to the air line.

3. After the connection is completed, a tightness test must be carried out. First, turn on the water in the water heater. After the water flow is normal, close the water outlet valve and check whether the water system is leaking. Then, close the water inlet valve, open the gas valve, and carefully check all gas joints and pipes for leaks with soapy water. After confirming that there are no leaks, test the ignition system. After operating correctly according to the instructions in the "Instruction Manual" and igniting the fire, open the water inlet valve and let the water heater run to observe if everything is correct before putting it into use. If any problems are found, they should be solved in time.

4. In general, gas pipes should be connected with thick pipes, especially for artificial gas water heaters. Liquefied petroleum gas water heaters can be connected with thin pipes, but the inner diameter of the connecting pipe of a 5-liter water heater must not be less than 9 mm. The inner diameter of the air inlet connecting pipe of a 5-liter water heater should be no less than 10 mm, and that of an 8-liter water heater should be no less than 12 mm.

5. The gas pipe and water pipe connecting the gas water heater should not be too long. If connected with a hose, the gas pipe should not exceed 1.2 meters and the water pipe should not exceed 3 meters. They should be well supported and fixed to avoid twisting and breaking. The water heater should be resistant to high temperatures and should be checked regularly to avoid water leaks.

6. The installation height of the water heater should be such that the fire viewing hole is level with the human eye. The water heater should not be installed above furniture. The smoke exhaust outlet of the water heater should be more than 600 mm away from the ceiling, and other open surfaces should be more than 300 mm away from combustibles.

The above is about the installation height of the water heater. The most suitable height is the level between the light outlet and the human eye. The water heater must be installed in a well-ventilated room. Never install it in a bathroom or bedroom. A strict test must be carried out. You can first pass water through the water heater. The installation height of the water heater must be checked. The water pipe of the gas pipe of the water heater should not be too long.
