Heat exchanger scale cleaning method

I believe that every household now has a water heater. The water heater has become a very convenient and fashionable bathing tool. It is mainly used when there is plenty of shower. The water heater heats quickly and hot water is available anytime and anywhere. However, we will find that many things will get dirty after being used for a long time. The same principle applies. After the water heater is used for a long time, scale will be produced. So what are the methods for cleaning the scale when changing water?

Specific steps for cleaning scale

1. Flushing: Before pickling, open-type flushing should be performed on the heat exchanger to ensure that there is no impurities such as mud and scale inside the heat exchanger. This can not only improve the pickling effect, but also reduce the acid consumption of pickling.

2. Pour the cleaning liquid into the cleaning equipment and then inject it into the heat exchanger.

3. Pickling: Soak the heat exchanger filled with acid solution statically for 2 hours. Then continue the dynamic cycle for 3 to 4 hours. During this period, the positive and reverse cleaning were performed alternately every 0.5 h. After pickling, if the pH value of the acid solution is greater than 2, the acid solution can be reused. Otherwise, the pickling solution should be diluted and neutralized before being discharged.

4. Alkali washing: After the pickling is completed, NaOH, Na, PO and softened water are prepared in a certain proportion, and the heat exchanger is alkali washed in a dynamic cycle to achieve acid-base neutralization so that the heat exchanger plates will no longer be corroded.

5. Water washing: After the alkali washing is completed, use clean softened water to repeatedly rinse the heat exchanger for 0.5 h to thoroughly rinse the residue in the heat exchanger.

6. Records: During the cleaning process, the time of each step should be strictly recorded to check the cleaning effect. In short, after cleaning, the heat exchanger should be pressure tested. It can only be used after passing the test.

Measures to prevent fouling of plate heat exchangers

1. In the entire system, the dirt remover and filter should be cleaned irregularly, and the pipe network should also be kept clean to prevent the heat exchanger from being blocked. In summary. Strictly following the cleaning method of the plate heat exchanger is an important guarantee for the normal operation of production.

2. When a new system is put into operation, the heat exchanger should be separated from the system and circulated for a period of time before the heat exchanger is connected to the system to prevent impurities in the pipe network from entering the heat exchanger.

3. Strictly control the water quality during operation. The water in the system and the softened water in the softening tank must be strictly tested for water quality. Only after passing the water quality test can they be injected into the pipe network.

The above is an introduction to the method of cleaning scale in the heat exchanger. I hope everyone can correctly understand the correct cleaning method. Because there will be a lot of scale in the pipes of the water heater itself, we need to clean the water heater regularly to avoid corrosion or blockage of the pipes due to too much scale for a long time.
